Wireline drill rods
Wireline drill rods
Drill Rods, DCDMA standard, Diamond Drilling
BWL NWL HWL PWL, NRQ, HRQ, NTW, HTW, PHD in 1.5M, 3M
The wireline drill rods are made of special geological steel pipe with high strength and toughness.
The drill rod threads are heat treated and tested by special gauge.
Roschen provide universal standard of drill rods with qualified material and heat treatment.
Wireline drill rods specifications
| Model | Drill Rod | Standard | Heat Treatment | Drill Rod Material | Drilling Depth (M) | |
| OD (mm) | ID (mm) | |||||
| BTW | Ø56.3 | Ø48 | DCDMA | Overall Tempering | 30CrMnSiA/XJY850 | 1000 |
| NTW | Ø73.3 | Ø64 | DCDMA | Overall Tempering | 30CrMnSiA/XJY850 | 900 |
| HTW | Ø91.3 | Ø81 | DCDMA | Overall Tempering | 30CrMnSiA/XJY850 | 800 |
| AQ | Ø44.5 | Ø34.9 | DCDMA | Overall Tempering | 30CrMnSiA/XJY850 | 1000 |
| BQ | Ø55.6 | Ø46 | DCDMA | Overall Tempering | 30CrMnSiA/XJY850 | 1200 |
| NQ | Ø69.9 | Ø60.3 | DCDMA | Overall Tempering | 30CrMnSiA/XJY850 | 1800 |
| HQ | Ø88.9 | Ø77.8 | DCDMA | Overall Tempering | 30CrMnSiA/XJY850 | 1800 |
| PQ | Ø114.3 | Ø103.2 | DCDMA | Overall Tempering | 30CrMnSiA/XJY850 | 1600 |
